SUNTEX - TS-110 Portable pH/ORP/Temp. Meter


  • Data Logger
  • RS-232 Output
  • Resolution up to 0.001pH



As high performance lab meter in your hand

The TS-110 meter features microprocessor design with IP65 waterproof protection. The simultaneous display of main measurement and temperature value make it idea for making field record. The three points calibration design enable a wide range of calibrated measurement. The TS-110  applies data logger and RS-232 interface. The advanced data logger function can automatically save the measurement with time interval up to 500 sets, and it can direct transmit through RS-232 interface to a computer or a printer. Hence, it not only can be as field measuring but also as field recording without hand writing or manually pressing the savebutton.

Features:

  • Light, handy, easy-to-use, IP65 water proof & low power consumption
  • Large LCD display with temperature indication
  • Automatic temperature compensation with PT-1000 or NTC probe
  • Auto-Read function
  • Gradually continuous sample measurements average function to enhance stability
  • 1/2/3-point auto calibration, showing offset and slope after calibration
  •  Low-power consumption system allows operation up to 1000 hours

Model

TS-110



Measuring mode

pH/ORP/Temperature

Measuring

range

pH

-2.00 ~ 16.00 pH/  -2.000~16.000pH

ORP

-1999 ~ 1999 mV /

-1999.9~1999.9mV

Temperature

-10.0~110.0°C

Resolution

&

Accuracy

pH

0.01pH/0.001pH,  ±0.01/±0.005 (± 1Digit)

ORP

1mV/0.1mV,  ±0.05% (± 1Digit)

Temperature

0.1°C,  ±0.2°C (Max.)

RS-232 interface

Single way transfer the data to a computer or a printer

Dual way by Modbus protocol

Data logger

Auto/Manual, 500 sets, (measurement, temp., time, date, ID number)

Auto-Read function

Yes

Auto power-off

Yes (Built-in timer)

Temperature Compensation

Automatic with PT-1000 or NTC 30K or manual adjustment

Calibration

pH

Auto Tech./NIST or Manually Any buffer solution calibration, up to 3 points calibration

Ambient Temperature

0~50°C

Storage Temperature

-20~70°C

Input impedance

1012Ω

Display

1/2” LCD display

Power Supply

4 x AA Batteries

Dimensions

170 mm x 80 mm x 38 mm (L x W x H)

Weight

0.35 kg

Certification

CE, IP 65
